Large Drill Bits Drill Spare Parts Carbon Steel For Mining Water Well Drilling

Description
DTH drill bits are widely used in underground mining, quarries, hydraulic and Hydro-Power Engineering,
water well drilling, Mineral exploration, anchoring hole drilling, geothermal engineering, Subway excavation,
another civil engineering. it has the advantage of high flatness, smooth hole wall, high rigid of drill rod and
hammer, independent of high axial thrust, no limit of drilling depth, low cost of devices and easiness to maintain.

Application
DTH drill bits range covers the most diverseapplications in mining, natural resources exploration, water wells,
quarries and civil works.

Product Information
JCDRILL has a comprehensive range of DTH drill bits to match all conceivable applications. Each bit is made from quality alloy steel, and has been precision machined to produce a perfect body, heat treated to the required hardness, given surface compression for fatigue resistance, and fitted with precision buttons manufactured in-house. These are deigned for specific applications for all rock types, hardness's and condition. Bit life and rate of penetration are the most important criteria in selecting the right bit for a particular application.

specification
JCDRILL Button Bits range covers hole diameter 3" and upwards upto 24". JCDRILL DTH Button Bits are
available for all Major DTH Hammer Brands.
DHD-3.5, Cop-34, M-30, A34-15, BR2,BR3
Panther, DHD -14, DH4,DHD-4,DHD-34OA,Cop-42, Cop-44,Mission 40, SD-4, QL-4, Secoroc-4" , Numa-4
DHD-16,DHD-160,DHD-360,QL-60,Mission 60, SD-6, Cop-62,Cop-64,Secoroc-6", Numa-6"
SD-8,DHD-380,COP-84,SECOROC-8'',NUMA-8, Mission 80
SD-10,NUMA-100
SD-12,NUMA-12

Bit Shank	Bit Diameter.(mm)
CIR-Series Low Air pressure DTH Bits
CIR65,HR65	65,68,75mm
CIR80,HR80	83,85mm
CIR90,HR90	85,90,110mm
CIR110,HR110	110,115,120,135mm
HR150,	155,160,165,170,180,210,220mm
1''-2''Middle Air pressure DTH Bits
BR1,BR2,HD25	64,70,76,80,82,90mm
3'' High Air pressure DTH Bits
COP32,BR3,HD35,IR3.5,COP34,QL30,M30	85,90,95,100,105mm
4'' High Air pressure DTH Bits
HD45,DHD340A,COP44,SD4,QL40,M40,HM4	105,110,115,120,127,130,133mm
5'' High Air pressure DTH Bits
HD55,DHD350,COP54,SD5,QL50,M50,HM5	130,135,140,146,152,165mm
6'' High Air pressure DTH Bits
HD65,DHD360,COP64,SD6,QL60,M60,HM6	152,155,165,171,190,203mm
8'' High Air pressure DTH Bits
HD85,DHD380,COP84,SD8,QL80,M80,HM8	200,203,216,222,226,229,,241,254,270,305mm
10'' High Air pressure DTH Bits
SD10,NUMA100	254,305,311,318,330mm
12'' High Air pressure DTH Bits
DHD1120,SD12,NUMA120,NUMA125	305,311,330,356,381mm

Advantages:
1. Computer analysis and laboratory trials have been used to optimize the number of buttons as well as
their size and positioning throughout the bit front.
2. Carbide has been carefully designed to minimize the risk of button loss and button failure
3. The design of the bit body and the frontal sludge grooves provides uniform flushing with reduces steel
wash on both bit and the hammer.
4. Material processes and multiple heat treatment have focussed on achieving maximum resistance to fatigue failure.
